Comfort control unit

400V, Aqualift Duo, 2x2.5-4.0 A, AX

28762

KESSEL Comfort control unit, nominal current 2,5 - 4 A, yes, potential-free contact yes, duo pump

  • Self-diagnosis system (SDS)
  • Potential-free contact for faults/warnings
  • Reminder for when maintenance is due
Item no. 28762
GTIN 4026092054611
Price group 20

Comfort control unit 400V, Aqualift Duo, 2x2.5-4.0 A, AX
Comfort control unit for lifting stations or pumping stations. Suitable for 400 V double stations. Optional connection options for float switches, conductivity probes, and level probes on the terminal strip. User-friendly menu navigation on the multi-line display. Menu navigation in six languages. Simple selection of the system to be connected with preset, system-specific operating parameters. Display of current measured values. Simple adjustment of function-relevant parameters, with integrated operating hour counter. With self-diagnosis system (SDS) for monitoring pump, sensors and battery back-up. Improper installation or operating faults trigger an optical and acoustic alarm signal. Forwarding of a collective fault and alarm signal via optional potential-free contact or integrated serial interface for a GSM modem. Variant Series: ab 03/2010 Type of system: duo pump General characteristics Colour: grey System type: Duo Dimensions Net weight: 3,17 kg Gross weight: 3,83 kg Packaging dimension: length: 400 mm Packaging dimension: width: 250 mm Packaging dimension: height: 190 mm Pumping device Connection type: Direct connection Rated current: 2,5 - 4 A Control Control unit: Comfort Motor protection switch: yes Protection class control unit: IP 54 Connection type: Direct connection Potential-free contact: yes GSM interface: yes USB interface: no Log book function: yes Multi-line display: yes Battery buffering: yes Self-diagnosis system (SDS): yes
  Title Item no.
  Title Item no.
  Title Item no.
  Title Item no.
  • Control unit (schaltgeraet): Comfort
  • ATEX (atex): yes
  • TÜV test mark (pruefzeichen): ID 1111241940
  • (niveauerfassung_art):
