Shell Kit
for Pumpfix F, without nozzles


KESSEL Shell Kit for Pumpfix F, without nozzles, wastewater with sewage, exposed drainage pipe, with submersible pumps, type of cover Protective cover
Item no. | 24000-RBK |
---|---|
GTIN | 4026092097076 |
Price group | 30 |
Shell Kit for Pumpfix F, without nozzles
KESSEL shell kit for Pumpfix F, without sockets Shell kit consisting of a drain body and upper section. The inlet and outlet sockets are not included. For combination with a KESSEL technology kit for creating a Pumpfix F backwater pumping station. General characteristics Colour: black Type of wastewater: with sewage Installation situation: exposed drainage pipe Delivery state: Pre-mounted for final assembly on site (pumps and sensor system must be fitted on site and control unit must be connected) Approval: Z-53.2-388 Motor type: KSM 140 Type de protection moteur: IP 68 (3m/48h) Dimensions Net weight: 8,06 kg Gross weight: 9,59 kg Packaging dimension: length: 785 mm Packaging dimension: width: 385 mm Packaging dimension: height: 465 mm Tank/drain body Socket version: optional Coverage features Type of cover: Protective cover Cover material: Polymer Colour of cover: transparent Width of cover: 350 mm Height of cover: 165 mm Length of cover: 542 mm Locking: Clip closure
Title | Item no. |
---|
Title | Item no. |
---|
Title | Item no. |
---|
Title | Item no. |
---|
CAD Data | |
---|---|
Approval |
- Type of cover (abdeckungsart): Protective cover
- Cover material (abdeckung_material):
Polymer
- Installation situation (einbausituation): exposed drainage pipe
- Type of wastewater (abwasserart_de):
with sewage
