Ferrofix cleanout

Sys 100, tileable, odour-tight

The Ferrofix cleanout made of 304 stainless steel serves as an upper section for direct connection on pipes and is equipped with a closed, screwed cover plate. Backwater-proof up to 0.5 bar.

Item no. 27177-PLF
GTIN 4026092090855
Price group 70

    Ferrofix cleanout Sys 100, tileable, odour-tight
    The Ferrofix cleanout made of 304 stainless steel serves as an upper section for direct connection on pipes and is equipped with a closed, screwed cover plate. Backwater-proof up to 0.5 bar. Variant System: 100 Backflow preventer: up to 0.5 bar Dimensions Net weight: 0,96 kg Gross weight: 1,06 kg Height: 100 mm Packaging dimension: length: 195 mm Packaging dimension: width: 195 mm Packaging dimension: height: 182 mm Coverage features Type of cover: tileable cover plate Cover material: Stainless steel 14301 Width of cover: 146 mm Length of cover: 146 mm Cover locking: screwed Load class: L 15 (EN 1253-1) Tightness: gas-tight Upper section material: Stainless steel 14301
      Title Item no.
      Title Item no.
      Title Item no.
      Title Item no.
    • Cover material (abdeckung_material): Stainless steel 14301
    • Upper section material (material_aufsatzstueck): Stainless steel 14301
    • Type of cover (abdeckungsart): tileable cover plate
    • Load class (belastungsklasse): L 15 (EN 1253-1)
    • Cover locking (verriegelung): screwed
    • (abdichtung_aufsatzstueck):
