General characteristics
Type of wastewater: with sewage
Dimensions
Net weight: 26 kg
Gross weight: 28 kg
Packaging dimension: width: 350 mm
Packaging dimension: height: 380 mm
Packaging dimension: length: 585 mm
Pumping device
Pump control: SPF 4500
Connection type: Direct connection
Rated current: 7,5 A
Length of mains cable for pump: 5 m
Self-diagnosis system (SDS): I
T-DSC: no
Protection class control unit: IP 68 (3m/48h)
DSC: controlled via control unit
Max. temperature (permanent) of conveyed material: 40 °C
Max. pumping height: 20 m
Speed: 2850 U/min
Power P1: 4,5 kW
Power P2: 3,5 kW
Operating mode: S3 - 50 %
Type of pump connection cable: H07RN-F 7G 1.5 mm²
Control
Mains frequency: 50 Hz
Operating voltage: 400 V
Connection type: Direct connection
