General characteristics
Type of wastewater: with sewage
Dimensions
Net weight: 25 kg
Gross weight: 27 kg
Packaging dimension: width: 182 mm
Packaging dimension: height: 313 mm
Packaging dimension: length: 182 mm
Pumping device
Pump control: SPF 1400
Connection type: Direct connection
Rated current: 7,3 A
Length of mains cable for pump: 5 m
Self-diagnosis system (SDS): I
T-DSC: yes
Protection class control unit: IP 68 (3m/48h)
DSC: integrated
Max. temperature (permanent) of conveyed material: 40 °C
Max. pumping height: 7 m
Speed: 1370 U/min
Power P1: 1,6 kW
Power P2: 1,1 kW
Operating mode: S3 - 50 %
Control
Mains frequency: 50 Hz
Operating voltage: 230 V
Connection type: Direct connection
