General characteristics
Type of wastewater: with sewage
Dimensions
Net weight: 32 kg
Gross weight: 34 kg
Packaging dimension: width: 182 mm
Packaging dimension: height: 313 mm
Packaging dimension: length: 182 mm
Pumping device
Pump control: SPF 4500
Connection type: Direct connection
Rated current: 7,7 A
Length of mains cable for pump: 5 m
Self-diagnosis system (SDS): I
T-DSC: no
Protection class control unit: IP 68 (3m/48h)
DSC: controlled via control unit
Max. temperature (permanent) of conveyed material: 40 °C
Max. pumping height: 20 m
Speed: 2845 U/min
Power P1: 4,5 kW
Power P2: 3,7 kW
Operating mode: S1
Type of pump connection cable: H07RN-F 7G 1.5 mm²
Control
Mains frequency: 50 Hz
Operating voltage: 400 V
Connection type: Direct connection
