Ferrofix upper section gl. flange
Sys 200, closed cover, 304 SST
KESSEL Ferrofix upper section gl. flange, height 110 mm, length 200 mm, width 200 mm, type of cover closed cover plate with drain slots, locking screwed, design cover
- Made of a particularly hygienic and mechanically highly resistant stainless steel
- Multiple combinations with suitable drain bodies
Item no. | 48954-S-V2A-KF |
---|---|
GTIN | 4026092090831 |
Price group | 70 |
Ferrofix upper section gl. flange Sys 200, closed cover, 304 SST
Used in combination with a drain body of the KESSEL modular system 200, the Ferrofix stainless steel upper section with glued flange is suitable for indoor point drainage. Variant System: 200 Waterproofing layer on the upper section: Adhesive flange (suitable for moisture barriers) Water exposure class in accordance to DIN 18534-1 (up to and including): W3-I Dimensions Net weight: 4 kg Gross weight: 4,3 kg Type of height adjustability: vertically adjustable upper section Length: 300 mm Height: 110 mm Packaging dimension: length: 300 mm Packaging dimension: width: 300 mm Packaging dimension: height: 110 mm Coverage features Type of cover: closed cover plate with drain slots Cover material: Stainless steel 14301 Height of cover: 15 mm Surface: Polished SST Locking: screwed Load class: L 15 (EN 1253-1) Rim width: 200 mm Rim length: 200 mm Shape of upper section: square Upper section material: Stainless steel 14301
Title | Item no. |
---|
Title | Item no. |
---|
Title | Item no. |
---|
Title | Item no. |
---|
CAD Data |
---|
- Cover material (abdeckung_material): Stainless steel 14301
- Upper section material (material_aufsatzstueck): Stainless steel 14301
