Upper section

Class B, Round slotted grating, d:230 mm

67985

The telescopic height-adjustable upper section made of Ecoguss. The recyclable composite material meets the highest sound insulation requirements, is resistant to aggressive media, temperature resistant and has a permanently corrosion-free surface. It can be exposed to flames for short periods, 100 up to 400 degrees Celsius.

Item no. 67985
GTIN 4026092038949
Price group 10

    Upper section Class B, Round slotted grating, d:230 mm
    The telescopic height-adjustable upper section made of Ecoguss. The recyclable composite material meets the highest sound insulation requirements, is resistant to aggressive media, temperature resistant and has a permanently corrosion-free surface. It can be exposed to flames for short periods, 100 up to 400 degrees Celsius. Variant System: 200 General characteristics Colour: black Standard: EN 1253 ATEX: no Dimensions Net weight: 2,98 kg Gross weight: 3,35 kg Diameter: 230 mm Packaging dimension: length: 340 mm Packaging dimension: width: 340 mm Packaging dimension: height: 215 mm Coverage features Type of cover: Round slotted cover Cover material: Ecoguss Colour of cover: black Width of cover: 258 mm Height of cover: 198 mm Length of cover: 258 mm Locking: Lock & Lift Load class: L 15 / M 125 (EN 1253-1) Upper section material: Ecoguss
      Title Item no.
      Title Item no.
      Title Item no.
      Title Item no.
    48520 Odour trap Multistop, System 200 48520 Show
    67007 Locking key for Ecoguss slotted gratings,Lock & Lift 67007 Show
    680216 Slotted cover Ecoguss, d: 235 mm, B 125 680216 Show
    • Cover material (abdeckung_material): Ecoguss
    • Upper section material (material_aufsatzstueck): Ecoguss
    • (nennweite):
    • Type of cover (abdeckungsart): Round slotted cover
    • Load class (belastungsklasse): L 15 / M 125 (EN 1253-1)
    • (stutzen_ausfuehrung):
