EasyClean free Auto Mix & Pump grease separator

The all-rounder for exposed installation.

As good as it gets. The EasyClean free Auto Mix & Pump grease separator simply has everything: program-controlled, fully-automatic disposal and rinsing equipment, shredder-mix system, disposal pump,, direct disposal pipe and control unit. The contents of the closed tank are disposed of through permanently installed pipes into the disposal vehicle. The system’s own pimp is used if the disposal pipe is so long that the disposal vehicle’s pump is not sufficient. The shredder-mix system is used to circulate and homogenise the contents of the tank for easy disposal.

The grease separator is available in nominal sizes NS 2 to NS 10, which is sufficient for most businesses such as restaurants and hotels. It is also available in nominal sizes NS 15 to NS 50 for larger volumes of wastewater. In addition, we also offer individual solutions for specific requirements and installation situations.

Advantages  Article overview

The EasyClean free Auto Mix & Pump combines all advantages in one unit:

  • Direct disposal: Disposal via the direct disposal pipe – without opening the tank.
  • No odour emissions: The shredder-mix system ensures odourless disposal and cleaning.
  • Central control:  The shredder-mix system and refill inlet can be controlled via the control unit.
  • Disposal pump: For installation situations in which the disposal vehicle can no longer extract the wastewater.
  • Fully automatic: The disposal and rinsing take place fully automatically and program-controlled.

100 % corrosion-free – 20-year guarantee

Our grease separators are made of polyethylene. That makes them resistant to aggressive fatty acids and they are therefore particularly durable. Trust in KESSEL quality: In addition to the statutory provision, we provide a 20-year warranty with regard to the leak tightness, fitness for purpose and structural stability of tanks and upper sections.

SonicControl

The SonicControl automatic layer thickness measuring device with ultrasound sensor precisely monitors the temperature and thickness of the grease layer in grease separators. Owners/operating companies can verify the actual quantity of grease produced to the relevant authorities and optimise the necessary disposal cycles outside of standard requirements.

More information

Changeover socket

The flow direction can easily be changed on site thanks to the self-sealing changeover socket. A distinction no longer needs to be made between the “direction of flow right” or “direction of flow left” variants – making the design much easier.

Important: Stricter limit values!

When grease separators are used, the wastewater at the outlet has a residual value of lipophilic materials of about 300 mg/L. If the municipalities specify a limit value below 300 mg/L, biological grease treatment with a Bifena unit is necessary.

BIFENA biological grease treatment

EasyClean free Auto Mix & Pump

With SonicControl

  Nominal size (NS)Sludge bucketRefill inlet in accordance with DIN 1988Set-up area, widthSet-up area, length Item no.
93002.02/PVS93002.02/PVS 2 yes yes 841  mm 1,736  mm 93002.02/PVS
Show
93003.02/PVS93003.02/PVS 3 yes yes 841  mm 1,736  mm 93003.02/PVS
Show
93004.02/PVS93004.02/PVS 4 yes yes 842  mm 2,116  mm 93004.02/PVS
Show
93007.02/PVS93007.02/PVS 7 yes yes 1,108  mm 2,147  mm 93007.02/PVS
Show
93010.02/PVS93010.02/PVS 10 yes yes 1,108  mm 2,822  mm 93010.02/PVS
Show
93015-02-PVS-L93015-02-PVS-L 15 yes yes 1,680  mm 3,530  mm 93015-02-PVS-L
Show
93015-02-PVS-R93015-02-PVS-R 15 yes yes 1,680  mm 3,530  mm 93015-02-PVS-R
Show
93020-02-PVS-L93020-02-PVS-L 20 yes yes 1,680  mm 3,530  mm 93020-02-PVS-L
Show
93020-02-PVS-R93020-02-PVS-R 20 yes yes 1,680  mm 3,530  mm 93020-02-PVS-R
Show

Without SonicControl

  Nominal size (NS)Sludge bucketRefill inlet in accordance with DIN 1988Set-up area, widthSet-up area, length Item no.
93002.01/PVS93002.01/PVS 2 yes yes 841  mm 1,736  mm 93002.01/PVS
Show
93003.01/PVS93003.01/PVS 3 yes yes 841  mm 1,736  mm 93003.01/PVS
Show
93004.01/PVS93004.01/PVS 4 yes yes 842  mm 2,116  mm 93004.01/PVS
Show
93007.01/PVS93007.01/PVS 7 yes yes 1,108  mm 2,147  mm 93007.01/PVS
Show
93010.01/PVS93010.01/PVS 10 yes yes 1,108  mm 2,822  mm 93010.01/PVS
Show
93015-01-PVS-L93015-01-PVS-L 15 yes yes 1,680  mm 3,530  mm 93015-01-PVS-L
Show
93015-01-PVS-R93015-01-PVS-R 15 yes yes 1,680  mm 3,530  mm 93015-01-PVS-R
Show
93015-06-PVS93015-06-PVS 15 yes yes 1,600  mm 3,755  mm 93015-06-PVS
Show
93015.01/PVS
15 yes yes 1,620  mm 3,560  mm 93015.01/PVS
Show
93020-01-PVS-L93020-01-PVS-L 20 yes yes 1,680  mm 3,530  mm 93020-01-PVS-L
Show
93020-01-PVS-R93020-01-PVS-R 20 yes yes 1,680  mm 3,530  mm 93020-01-PVS-R
Show
93020-06-PVS93020-06-PVS 20 yes yes 1,600  mm 4,760  mm 93020-06-PVS
Show
93020.01/PVS
20 yes yes 1,620  mm 4,510  mm 93020.01/PVS
Show
93025-06-PVS93025-06-PVS 25 yes yes 1,600  mm 5,140  mm 93025-06-PVS
Show
93030-06-PVS93030-06-PVS 30 yes yes 1,600  mm 5,160  mm 93030-06-PVS
Show
93030.01/PVS
30 yes yes 1,620  mm 4,860  mm 93030.01/PVS
Show
93035.01/PVS
35 yes yes 1,770  mm 6,480  mm 93035.01/PVS
Show
93040.01/PVS
40 yes yes 1,870  mm 6,680  mm 93040.01/PVS
Show
93050.01/PVS
50 yes yes 1,882  mm 6,680  mm 93050.01/PVS
Show

Not found the right product?

In addition to our standard grease separators we also develop individual solutions on request for special requirements in terms of form, function and dimensioning.

Customised solutions
