Ferrofix upper section glued flange

Sys 200, closed cover, 304 SST

PDF product data sheet

Used in combination with a drain body of the KESSEL modular system 200, the Ferrofix stainless steel upper section with glued flange is suitable for indoor point drainage.

  • Made of a particularly hygienic and mechanically highly resistant stainless steel
  • Multiple combinations with suitable drain bodies
Item no. 48954-S-V2A-KF
GTIN 4026092090831
Discount group 3

Ferrofix upper section glued flange Sys 200, closed cover, 304 SST
Used in combination with a drain body of the KESSEL modular system 200, the Ferrofix stainless steel upper section with glued flange is suitable for indoor point drainage. Version: System: 200 Type of waterproofing layer: Waterproofing layer Waterproofing layer on the upper section: Adhesive flange (suitable for moisture barriers) Water exposure class in accordance to DIN 18534-1 (up to and including): W3-I Dimensions: Height: 110 mm Vertical adjustment: vertically adjustable upper section Coverage features: Type of cover: closed cover plate with drain slots Cover material: 304 stainless steel Load class: L 15 (EN 1253-1) Height: 15 mm Surface: polished Locking: screwed Grating: Rim length: 200 mm Rim width: 200 mm Shape of upper section: square Upper section material: 304 stainless steel
  Title Item no.
  Title Item no.
  Title Item no.
  Title Item no.
  • Waterproofing layer on the upper section (ATTR-251): Adhesive flange (suitable for moisture barriers)
  • Complete article (ATTR-254): no
  • Electrical connection available (ATTR-256): no
  • Connection to the BCS, BAC (ATTR-257): no
  • Shape of upper section (ATTR-259): square
  • Type of drainage (ATTR-260): Point drain
  • Grating/channel shape (ATTR-261): square
  • Type of drainage (ATTR-263): open channel
  • Rim length (ATTR-111B): 200  MMT
  • Rim width (ATTR-111C): 200  MMT
  • Height (ATTR-A6C): 110  MMT
  • Volume (ATTR-320): 0.0  MTQ
  • Packaging dimension: length (ATTR-325): 200  MMT
  • Packaging dimension: width (ATTR-326): 200  MMT
  • Packaging dimension: height (ATTR-327): 175  MMT
  • Dimensions (ATTR-323): 1264X254X136MM
  • Number of packages (ATTR-321): 0
  • Type of waterproofing layer (ATTR-170): Waterproofing layer
  • System (ATTR-244): 200
  • Type of cover (ATTR-A21): closed cover plate with drain slots
  • Load class (ATTR-A2B): L 15 (EN 1253-1)
  • Locking (ATTR-A2D): screwed
  • Cover material (ATTR-A2E): 304 stainless steel
  • Surface (ATTR-A2F): polished
  • Height (ATTR-A2P): 15  MMT
  • Net weight (ATTR-A3A): 0  KGM
  • Gross weight (ATTR-A3B): 0  KGM
  • Vertical adjustment (ATTR-177): vertically adjustable upper section
  • Water exposure class in accordance to DIN 18534-1 (up to and including) (ATTR-242): W3-I
  • Upper section material (ATTR-231): 304 stainless steel
  • Brand (M-ATTR-001): KESSEL
  • Product group (M-ATTR-002): Drains
  • Product type (M-ATTR-003): Upper section
  • Product family (M-ATTR-004): Ferrofix
  • Product name (M-ATTR-005): Ferrofix
