Upper section

Class B, Round slotted grating, d: 230 mm

PDF product data sheet

The telescopic height-adjustable upper section made of Ecoguss. The recyclable composite material meets the highest sound insulation requirements, is resistant to aggressive media, temperature resistant and has a permanently corrosion-free surface. It can be exposed to flames for short periods, 100 up to 400 degrees Celsius.

Item no. 67985
GTIN 4026092038949
Price group 10

Upper section Class B, Round slotted grating, d: 230 mm
The telescopic height-adjustable upper section made of Ecoguss. The recyclable composite material meets the highest sound insulation requirements, is resistant to aggressive media, temperature resistant and has a permanently corrosion-free surface. It can be exposed to flames for short periods, 100 up to 400 degrees Celsius. General characteristics: Colour: black Standard: EN 1253, EN 752 Coverage features: Type of cover: Round slotted cover Cover material: Ecoguss Colour of cover: black Load class: L 15 / M 125 (EN 1253-1) Length: 258 mm Width: 258 mm Height: 198 mm Locking: Lock & Lift Upper section material: Ecoguss
  Title Item no.
  Title Item no.
  Title Item no.
  Title Item no.
Odour trap Multistop, System 200 48520
Locking key for Ecoguss slotted gratings, Lock & Lift 67007
Slotted cover Ecoguss, d: 235 mm, B 125 680216
  • Type of cover (ATTR-A21): Round slotted cover
  • Colour of cover (ATTR-A2A): black
  • Load class (ATTR-A2B): L 15 / M 125 (EN 1253-1)
  • Locking (ATTR-A2D): Lock & Lift
  • Cover material (ATTR-A2E): Ecoguss
  • Length (ATTR-A2M): 258  MMT
  • Width (ATTR-A2N): 258  MMT
  • Height (ATTR-A2P): 198  MMT
  • Upper section material (ATTR-231): Ecoguss
  • Diameter (ATTR-A107): 230  MMT
  • Brand (M-ATTR-001): KESSEL
  • Colour (ATTR-102): black
  • Standard (ATTR-9): EN 1253
  • Advantages text (M-ATTR-007): Major projects made easy thanks to easy to use hybrid material
  • Net weight (ATTR-A3A): 3.3  KGM
  • Gross weight (ATTR-A3B): 3.3  KGM
  • Volume (ATTR-320): 0.0  MTQ
  • Packaging dimension: length (ATTR-325): 340  MMT
  • Packaging dimension: width (ATTR-326): 340  MMT
  • Packaging dimension: height (ATTR-327): 215  MMT
  • Dimensions (ATTR-323): 340X340X215MM
  • Number of packages (ATTR-321): 0
  • Country of origin (ATTR-322): DE
